2019-2025 Project

Tendon-driven manipulators

Soft Material Tendon-Driven Serial Manipulators Prof. Dr. ir. Remco I. Leine (PI) Dr.-Ing. Bastian Deutschmann (PI) Universität Stuttgart DLR

The emerging field of Soft Robotics is still at an early stage. Most robots are designed for a lab environment and are at a point where reliability of mechanical and electronic devices is still limited and where control concepts are in its infancy. Consequently, real applications are rather scarce. To take a step forward towards real application scenarios, we will develop a soft material tendon-driven serial manipulator. We envision the serial manipulator to be composed of stacked joint modules from the first funding period. This manipulator will serve as technology demonstrator to explore the boundaries of what is possible with soft material. With standard tests for robotic manipulators, we aim at evaluating the soft material manipulator concerning whole body deformation, dexterity, precision, repeatability, speed and robustness against external impacts.

To increase the functional integration of the soft material, we investigate how to introduce hollow cavities in which the actuating tendons run freely without affecting the properties of the material. The dimensioning of these tendon channels, the tendons as well as the electro-mechanical actuators rely strongly on the possibilities to describe the physics of the manipulator. Therefore, we will set up a simulation environment for the analysis of the static and dynamic behavior of soft material manipulators. The simulation environment is characterized by the integration of tendon-actuation as well as alternative soft robotic specific actuation principles.

As ultimate goal, the soft manipulator’s endeffector can follow a predefined trajectory. For the intended model-based control strategies, three topics will arise. These are trajectory generation, trajectory tracking control and state estimation of the manipulator. These topics will be particularly challenging, as corresponding methods for rigid-link manipulators are not directly applicable. As continuously distributed sensors and actuators are missing, controlling a soft manipulator means to control a nonlinear system that is highly underactuated. An additional difficulty is caused by the tendons, which actuate only unilaterally. To generate trajectories, we will work on optimal control strategies that are able to resolve these specific difficulties. For the trajectory tracking problem, we strive for a model-based feedback control strategy that allows to incorporate a feedforward control action and that exploits the favorable dynamics of the manipulator with inherently stable equilibrium configurations.

Naturally, the development of the manipulator poses novel research questions concerning design, fabrication, modeling and control, which will be addressed in this project and whose answers will get us to a new generation of soft robots.



Publications



Dr.-Ing. Bastian Deutschmann (PI)
email web

Prof. Dr. ir. Remco I. Leine  (PI)
email   web

Dr. Simon R. Eugster
email   web

Oliver Sebastian Neumann
email

Tianxiang Dai
email

Jens Reinecke
email
